Parker 71215SN21N00N0D100C2 Solenoid Valve Skinner 2 Way 1/4″ NPT 24 VDC
Brand: Parker | Model: 71215SN21N00N0D100C2 | Condition: New | NEO SKU: 10699-2
Original price was: $147.06.$112.49Current price is: $112.49.
2 in stock
Free Shipping on orders over $50.
*(Domestic only)
Need it fast? Next Day Air available at check out.
Same Day Handling on orders prior to 2pm Eastern Monday – Friday
2 in stock
NEO SKU: 10699-2 | Category: Solenoid Valves & Coils
Product Details for New Parker 71215SN21N00N0D100C2 Solenoid Valve Skinner 2 Way 1/4″ NPT 24 VDC:
Condition: New
Brand: Parker
Model: 71215SN21N00N0D100C2
Country of Origin: USA
Product Notes
Multiple Quantities, price is per one (1) unit.
Parker 2-Way Normally Closed, 1/4″ NPT General Purpose Solenoid Valves | #71215SN21N00N0D100C2
Parker 2-Way Normally Closed, 1/4″ NPT Solenoid Valves provide operating pressures up to 600 PSI and flow factors up to 2.5 CV’s. They offer multiple body materials, mounting positions and coil options for all general purpose flow control applications.
Technical Specifications
Flow Factor 1 (Cv):1.1
Orifice 1 Size (inch):5/16
Voltage (V):24 VDC
Coil Type:DIN Form A
Power (Watts):10 Watts (DC)
Body Material:Stainless
Seal Material:NBR
Product Series:7000 Series
Valve Type:2-Way
Function:Normally Closed
Port Size:1/4 inch
Input Voltage:24 VDC
Body Material:Stainless
Seal Material:NBR
Orifice 1 Size:5/16 inch
Flow Coefficient 1:1.1 Cv
Power Consumption:10 Watts (DC) W
Coil Type:DIN Form A
Maximum Pressure Differential:3 psi (DC) psi
Number of Ports:2
Actuation Type:Direct Acting
Media:General Purpose for Air, Liquids and Gases
Port Type:NPT
Orifice 2 Size:n/a
Flow Coefficient 2:n/a
Minimum Pressure Differential:0 psi
Minimum Fluid Temperature:0 °F
Maximum Fluid Temperature:185 °F
Coil Specifications Met:NEMA 4X
Item Information
Parker’s 2-Way Normally Closed 1/4″ NPT Solenoid Valves are used in a wide variety of applications ideally suited for general purpose air, liquids and gases. These valves are available in stainless steel and brass construction. Coil options are available in 1/2″ NPT Conduit and DIN Form A in Class F and H or NEMA 4X, 7 or 9 specification.
Markets:
• Commercial Equipment
• Food & Beverage
• Industrial Automation
• Oil & Gas
• Process Control
• Transportation
Features/ Benefits:
• High Quality Standards of Skinner® and Gold Ring™ Brand
• Modular Design
• Long Life
• Tight Shutoff
Applications:
• Instrumentation Equipment
• Analyzers and Diagnostic Equipment
• Medical and Dental Equipment
• Portable Welding Equipment
• Spraying Equipment
• Lubrication Equipment
• Beverage Dispensing & Vending machines
• Oil Burners
• Humidification and Misting Equipment
• Mobile Fuel Shut Off
• Textile and Dry Cleaning Equipment
• Commercial Dishwashers
• Commercial Laundry and Dryers
• Air Horns
• Pneumatic Fan Clutch
• Irrigation Equipment
MFG Description
Parker Hannifin designs and manufactures high-quality motion and control technologies, including hydraulic systems, pneumatic components, and filtration products, providing reliable solutions for various industries.
MFG URL
For more information about this product or Parker, check out their website: https://parker.com
